IF-01
Process PipingProcess Piping (SS / MS / HDPE)
Techno Aid Inc undertakes complete process piping fabrication and installation for industrial plants across Maharashtra. We handle general utility piping, process piping, and service lines in Stainless Steel (SS), Mild Steel (MS), and HDPE materials. Our work covers design review, material procurement, spool fabrication, field installation, pressure testing, and documentation as per project P&IDs.
All piping work is carried out by qualified and certified welders. We perform hydrostatic, pneumatic, and radiographic testing (RT) as required. Our piping team is experienced in chemical plants, water treatment plants, pharmaceutical utilities, and general industrial facilities.
- Fabrication of pipe spools in shop and field as per isometric drawings
- SMAW, GTAW (TIG), and GMAW (MIG) welding processes
- Hydrostatic and pneumatic pressure testing as per P&ID requirements
- Radiographic testing (RT) and dye penetrant testing (DPT) available
- Pipe supports, hangers, and expansion joints fabrication and installation
- Insulation: hot & cold pipe insulation with aluminum cladding
- Complete documentation: weld maps, test reports, material test certificates (MTC)
IF-02
Pharmaceutical Piping – PW / WFI / Clean SteamPharmaceutical Piping (PW / WFI / Clean Steam)
Techno Aid Inc specializes in high-purity hygienic SS piping systems for pharmaceutical and biotech facilities. We design and install Purified Water (PW) distribution loops, Water for Injection (WFI) systems, and Clean Steam lines compliant with FDA, GMP, ISPE, and ASME BPE standards. These systems are critical to maintaining the water quality required by pharmaceutical manufacturing processes.
All pharmaceutical piping is fabricated from SS 316L seamless tubes with orbital welding to ensure consistent, fully penetrated, crevice-free welds. We provide complete IQ/OQ documentation, passivation certificates, and system validation support for regulatory submissions.
- SS 316L seamless tube piping for PW, WFI, and Clean Steam systems
- Orbital welding with automatic and manual TIG options
- Electropolishing and passivation (nitric acid / citric acid) of all wetted surfaces
- Slope and drainability as per ASME BPE and ISPE guidelines
- Tri-clamp and DIN hygienic fittings throughout
- Complete IQ/OQ documentation for regulatory compliance
- Weld log, coupon records, borescope inspection reports
- Hydrophobic vent filters and sampling points as per design
IF-03
Structural FabricationStructural Fabrication (MS & SS)
Techno Aid Inc executes structural steel fabrication for industrial platforms, mezzanine floors, pipe racks, equipment support structures, walkways, stairways, handrails, and industrial building structures. All structural work is carried out as per design drawings and IS structural standards using mild steel (MS) or stainless steel (SS) as required.
We have an in-house fabrication facility equipped with CNC flame cutting, plasma cutting, press braking, and welding stations. Our fabrication team handles high-quantity and project-specific structural requirements with precision and quality documentation.
| Structure Type | Material | Standard |
|---|---|---|
| Platforms & Mezzanines | MS (IS 2062 Gr. B) | IS 800 / IS 1161 |
| Pipe Racks & Sleepers | MS / SS 304 | IS 800 / ASME |
| Stairways & Handrails | MS / SS 304 / SS 316 | IS 4923 / Factory Act |
| Equipment Skid Frames | MS / SS 304L | IS 2062 / Client Spec |
| Industrial Sheds | MS (Pre-engineered) | IS 800 / IS 875 |
- In-house CNC plasma/flame cutting and press braking
- SMAW, GMAW, GTAW welding with qualified welders (BIS/ASME)
- Surface treatment: shot blasting (SA 2.5), epoxy priming, and painting as per specification
- Hot-dip galvanizing (HDG) option for outdoor and corrosive environments
- Third-party inspection and QAP documentation
- Modular fabrication for site ease of erection
IF-04
Customize Storage TanksCustomize Storage Tanks (SS & MS)
Techno Aid Inc designs and fabricates custom storage tanks, process vessels, and chemical storage solutions in Stainless Steel (SS 304 / SS 316 / SS 316L) and Mild Steel (MS) for industrial applications. Our tanks are fabricated to client-specific capacities, dimensions, pressure ratings, and nozzle arrangements in our in-house workshop.
We manufacture open top tanks, closed top tanks, vertical and horizontal tanks, conical bottom tanks, dish-end pressure vessels, and underground tanks. All tanks are fabricated as per relevant IS / ASME standards and undergo hydrostatic testing, dimensional inspection, and surface finishing before dispatch.
- Vertical, horizontal, conical bottom, and dish-end vessels
- Overhead (OHT), ground-level, and underground tank options
- Internal lining: rubber, FRP, epoxy, or electropolish for SS
- Agitator and mixer provision as per process requirement
- Nozzles, manholes, vent, drain, level gauge, and instrumentation connections
- Hydrostatic testing at 1.5× design pressure before dispatch
- Insulation jacketing in SS/aluminum for temperature-sensitive storage
IF-05
Skid MountingSkid Mounting (Pre-Engineered Skid Units)
Techno Aid Inc fabricates pre-engineered and pre-assembled skid-mounted systems for water treatment plants, chemical dosing systems, utility systems, and process packages. Skid-mounted systems are fully assembled, piped, wired, and tested at our workshop before delivery, significantly reducing site installation time and cost.
Each skid is custom-designed with a structural MS or SS frame, complete with all equipment, piping, valves, instruments, control panel, and electrical connections. The complete unit is factory-accepted tested (FAT) and arrives on site ready for simple connection and commissioning.
- Complete skid design: P&ID, GA drawing, electrical schematic
- MS painted or SS fabricated skid base frame
- All equipment, pumps, tanks, instruments pre-mounted and piped
- MCC / control panel with PLC or relay logic built-in
- Factory Acceptance Test (FAT) before dispatch
- Site commissioning support included
- Reduced site work: only utility connections required after delivery
IF-06
Plant Erection & CommissioningPlant Erection & Commissioning
Techno Aid Inc provides complete end-to-end plant erection and commissioning services for industrial facilities including water treatment plants, chemical plants, pharmaceutical utilities, and general process plants. Our multi-disciplinary team handles mechanical erection, utility piping, electrical, instrumentation, and automation to bring the plant to full operational status.
We work from approved engineering drawings and carry out systematic construction as per a detailed project schedule (Gantt chart). Regular progress meetings, QA/QC inspection records, and handover documentation are maintained throughout the project lifecycle. We offer both lump-sum turnkey contracts and item-rate execution models.
| Discipline | Scope of Work |
|---|---|
| Civil & Foundation | Equipment foundations, anchor bolting, grouting, civil structures |
| Mechanical | Equipment installation, alignment, coupling, grouting |
| Piping | Process, utility, instrument piping; hydrotest; insulation |
| Electrical | MCC, panels, cabling, earthing, lighting, DG connection |
| Instrumentation | Field instruments, control valves, transmitters, cable trays |
| Automation | PLC/SCADA programming, loop testing, commissioning |
- Turnkey and item-rate execution models available
- Civil, mechanical, electrical, instrumentation – all under one contract
- Detailed project schedule with weekly progress tracking
- QA/QC documentation: inspection test plans (ITP), NCR management
- Pre-commissioning (flushing, loop check) and commissioning support
- Performance testing and handover documentation
- Post-commissioning AMC and O&M services available
