Seawater Desalination / RO Systems / Containerized RO
Techno Aid Inc designs and commissions high-pressure Reverse Osmosis systems for seawater desalination and brackish water treatment. Our SWRO (Seawater Reverse Osmosis) plants are engineered to handle TDS levels up to 45,000 ppm and deliver potable or process-grade water with TDS below 500 ppm.
We offer systems in containerized, skid-mounted, and conventional plant formats to suit remote coastal locations, offshore platforms, and industrial facilities. Energy Recovery Devices (ERD) are integrated in larger systems to significantly reduce power consumption and operational costs.
Key Features & Benefits
- High-pressure pump with Energy Recovery Device (ERD)
- Duplex SS and FRP high-pressure piping and vessels
- Pre-treatment: multimedia filter, cartridge filter, antiscalant dosing
- Containerized format for remote or offshore deployment
- Automatic flush and membrane cleaning systems
- SCADA / PLC automation with remote monitoring
- Handles seawater TDS up to 45,000 ppm
- Produced water meets potable or process-grade standards
Technical Specifications
| Parameter | Specification |
|---|---|
| System Type | SWRO / BWRO (Seawater / Brackish Water RO) |
| Feed TDS | Up to 45,000 ppm (seawater) |
| Product TDS | < 500 ppm (potable grade) |
| Operating Pressure | 50 – 80 bar (SWRO) |
| Recovery Rate | 35 – 45% (SWRO) |
| Membrane Type | Seawater grade thin-film composite (TFC) |
| Energy Recovery | Pressure Exchanger (ERD) / Turbocharger |
| Pre-treatment | MMF + CF + Antiscalant dosing |
| Formats | Containerized / Skid-Mounted / Conventional Plant |
| Capacity | 1 KLD to 5000 KLD |
| Automation | PLC / HMI with SCADA |
Industries & Applications
How It Works
Seawater is pre-filtered through multimedia and cartridge filters to remove particulates. Antiscalant and other chemicals are dosed to prevent membrane fouling. High-pressure pumps (50–80 bar) force the feed water through spiral-wound seawater RO membranes, where salt and dissolved solids are rejected. The energy recovery device captures pressure from the concentrate stream, dramatically reducing power consumption. Permeate (product water) passes through post-treatment (remineralisation or pH correction) before delivery.
