Customize Storage Tanks (SS & MS)

IF-04 · Industrial Fabrication

Customize Storage Tanks (SS & MS)

Techno Aid Inc designs and fabricates custom storage tanks, process vessels, and chemical storage solutions in Stainless Steel (SS 304 / SS 316 / SS 316L) and Mild Steel (MS) for industrial applications. Our tanks are fabricated to client-specific capacities, dimensions, pressure ratings, and nozzle arrangements in our in-house workshop.

We manufacture open top tanks, closed top tanks, vertical and horizontal tanks, conical bottom tanks, dish-end pressure vessels, and underground tanks. All tanks are fabricated as per relevant IS / ASME standards and undergo hydrostatic testing, dimensional inspection, and surface finishing before dispatch.

Tank Types We Fabricate

Tank Type	Material Options	Application
Vertical Flat / Dish Bottom	SS 304 / SS 316L / MS	Water, chemical, process storage
Conical Bottom Tank	SS 304 / SS 316L	Pharma, food, slurry discharge
Horizontal Tank	MS / SS 304	Fuel, chemical, utility
Overhead Tank (OHT)	SS 304 / LLDPE / MS	Water supply, dosing systems
Underground / Buried Tank	MS (coated) / HDPE lined	Fuel, ETP sumps, WTP
Pressure Vessel (Dish End)	SS 316L / CS (IS 2062)	Compressed air, process vessels
Jacketed / Insulated Tank	SS 316L inner / SS 304 outer	Hot/cold process storage

Key Features & Options

• Vertical, horizontal, conical bottom, and dish-end vessels
• Overhead (OHT), ground-level, and underground tank options
• Internal lining: rubber, FRP, epoxy, or electropolish for SS
• Agitator and mixer provision as per process requirement
• Nozzles, manholes, vent, drain, level gauge, and instrumentation
• Hydrostatic testing at 1.5× design pressure before dispatch
• Insulation jacketing in SS/aluminum for temperature-sensitive storage
• Legs, lugs, saddle supports as per GA drawing
